AF40

WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE

Our outdoor projector enclosure AF40, thanks to its heating and cooling system, allows the installation of any beamer in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box. With our waterproof, protective housing you will be able to have perfect year-round outdoor projections and video mappings without having to worry about heat, cold, dust rain or snow. Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF40 protection performs an automatic temperature check and activates the heating and cooling system both during the day (when the projector is switched off) and at night when the projector is working. The AF40 has also been designed to be installed to the ceiling or, in general, to any suitable support structure. If this model doesn’t suit your video projector, we can customize it!



INTERNAL SIZES OF THE AF40 MODEL
METRIC UNITS ENGLISH UNITS

width

880 mm

34.7"

height

450 mm

17.7"

depth

1250 mm

49.2"

Enclosures suitable for projectors

ALL THE MEASURES ARE CUSTOMIZABLE ACCORDING TO YOUR VIDEO PROJECTOR

SPECIFICATIONS:

WEIGHT: 170,0 kg (374.8 lbs)
MAX CONSUMPTION COOLING MODE: 220 W / 1,0 A
MAX CONSUMPTION DURING HEATING AND DEHUMIDIFICATION MODE: 610 W / 2,8 A

FILL THE FORM TO REQUEST
